Airtac 3V100 Solenoid Valve 3V11006NCC
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
AirTAC 3V100-06NCC Solenoid Valve Specifications
- Model: 3V11006NCC
- Type: 3/2-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure: 0.15–0.7 MPa (21.7–101.5 PSI)
- Voltage tolerance: ±10% (all variants)
- Voltage options:
- DC12V (2.5W)
- DC24V (2.2W)
- AC110V 50/60Hz (3.5VA)
- AC220V 50/60Hz (3.8VA)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Flow coefficient (Cv): 0.65
- Max operating frequency: 5Hz (with load)
- Weight: 180g ±5g (without connector)
- Dimensions: 50mm(L) × 35mm(W) × 65mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (with no icing)
- Ambient humidity: 35–95% RH
- Protection rating: IP67 (coil assembly)
- Service life: ≥10 million cycles (under rated conditions)
High-cycle electromagnetic valve with precision-machined stainless steel plunger system, featuring dual-chamber design for stable operation under pressure fluctuations. The encapsulated coil assembly provides enhanced dust/water resistance, while the direct-acting mechanism eliminates minimum pressure requirements. Compatible with ISO 8573-1:2010 [7:4:4] compressed air quality standards.
- High-speed pick-and-place robotic end effectors
- Textile machinery pneumatic cut-off systems
- Beverage filling line dosage control
- Semiconductor wafer handling vacuum/pressure switching
- Medical sterilization equipment gas control
Installation guidelines:
Maintain horizontal mounting position for optimal condensate drainage.
Use 5μm precision filter with automatic drain upstream.
For AC voltage models, install surge absorber when switching inductive loads.
| Property | Property Value |
|---|---|
| sku | 3V11006NCC |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC 110V |
