AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageDC12V
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF)
Twelve volts DC is the coil voltage on this 3V110-06NCF, which makes it a candidate for battery-fed panels, vehicle-mounted circuits and any control system already built around a 12V rail. Functionally it is a 3-port, 2-position valve, normally closed: with the coil off, the outlet is open to exhaust and only the supply port is blocked.
It is a genuine AirTAC part, one configuration among many in the 3V1 range - normally open and normally closed, five coil voltages, DIN plug or flying lead, plus the 3V-F manifold bases. This page carries no flow or pressure numbers because our datasheet for the family is not to hand; request them by RFQ and we will reply with the confirmed figures.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | DC12V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC12V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF) Is Used
Truck-mounted air controls
Switching a spring-return cylinder on a vehicle body - a tipper latch or tailgate lock - from the chassis 12V system.
Agricultural implement actuation
Operating a single-acting hopper or marker cylinder on a seeder where the tractor supplies 12V control power only.
Workshop filter blow-down
Pulsing compressed air through a small dust-collector filter cartridge from a benchtop 12V timer circuit.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF) the Right Part?
Three choices are already made in 3V110-06NCF: normally closed behaviour (outlet vented until energised), a 1/8in PT port, and a DC12V coil - the last one matters most, because a coil is wound for one voltage only and 12V is usually chosen for battery or vehicle panels. The electrical entry is a DIN plug. For larger single-acting actuators, move up to the bigger ports available in the family. Sizing data for the 3V1 range is not in our published set; give us the actuator details by RFQ and we will confirm from the datasheet. If your project needs a 3-port valve whose flow and coil power are documented up front, the AirTAC 3V2 (1/8in, 1/4in) and 3V3 (1/4in) series are the ones with published figures. Double-acting work needs a 5-port 4V valve instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCF) FAQ
Yes - pressure range, flow and coil power for the 3V1 family are all confirmed from the datasheet on request; just send the model code by RFQ. If published figures are needed immediately rather than on request, the AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) 3-port bodies are the documented alternative.
A solenoid coil is wound for a single voltage and the DC12V coil here cannot be converted by rewiring, so it must match a 12V control supply exactly. If your panel runs 24V or mains, order the matching voltage variant from the same family rather than adapting this one.
