AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally open
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB)
This is a 3-port, 2-position solenoid valve: one supply port, one outlet and one exhaust. Because this SKU is normally open, air passes from supply to outlet while the coil is unpowered, and energising the coil shuts the supply and vents the outlet to exhaust. That reversed behaviour is exactly what you want where a power failure or an emergency stop must leave the circuit in its open, passed-air state. The 1/8in port and DC24V coil with a DIN plug entry complete the configuration: it drops into a 24V DC control panel and screws onto a PT-threaded 1/8in line.
We stock this as a genuine AirTAC part and ship it as coded above. The wider family covers both normally closed and normally open versions, five coil voltages, DIN plug and flying-lead entries, and 3V-F manifold bases for multi-valve installations. Pressure range, flow and electrical consumption for this family are figures we do not publish here; tell us your application and we will confirm them from the datasheet.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally open |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NO | Normally open: air passes until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB) Is Used
Fail-open blow-off nozzle
On a parts-cooling station, the normally open state keeps the air jet running if the 24V control loop drops, so chips and swarf keep clearing off the fixture instead of welding to the cutter.
Venting a spring-return clamp
Energising the coil exhausts a single-acting clamping cylinder and lets its spring retract the clamp - useful on a press-loading station where the clamp must release under fault conditions.
Pilot signal for a larger valve
Use the 1/8in outlet as the pilot line feeding a bigger process valve on a bottling or filling line, with the normally open behaviour holding the pilot on through a control-power outage.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB) the Right Part?
Choose NO when the safe or required condition is air flowing at the outlet with power off, and NC when it should be shut. Pick the port to match the line: M5 and 1/8in suit compact single-acting actuators and blow circuits, 1/4in and 3/8in suit larger ones. The coil voltage is fixed at manufacture - a DC24V coil cannot be rewired for another supply, so match it to your panel before ordering. DIN plug entry gives a socketed, easily replaced connection; flying lead (suffix I) arrives pre-wired. For several valves on one machine, a 3V-F manifold base shares one air feed and one wiring loom across all stations, with valves ordered separately.
One caution on sizing: published flow figures for this family are not in our hands, so ask us to check the valve against your actuator volume before you order. If you need a 3-port valve with published flow and coil power available today, the AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) direct-acting bodies carry full datasheet figures in our documentation. If your cylinder is double-acting, a 3/2 valve will not drive it - you need a 5-port valve from the AirTAC 4V series.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NOB) FAQ
Those figures sit in the manufacturer datasheet rather than on this page, so send us an RFQ and we will confirm the operating pressure range, flow capacity and coil consumption for your operating conditions. If you need a 3-port valve whose published figures are on the product page right now, the AirTAC 3V2 (1/8in and 1/4in) and 3V3 (1/4in) bodies are fully documented in our range.
Normally open means air flows from supply to outlet while the coil is off; switching it on shuts the supply and exhausts the outlet. Choose NO where a power loss must leave the circuit passing air, and the NC version where it must leave it shut. Either way, a 3/2 valve has only one outlet, so it suits single-acting (spring-return) actuators and blow circuits - a double-acting cylinder needs two outlet ports, which means a 5-port valve from the AirTAC 4V series.
