Airtac 3V100 Solenoid Valve 3V11006NOBI
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
3V11006NOBI
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pilot Operation: Optional internal pilot or external pilot configurations;
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
Operational Guidance:
Requires 5-7μm filtration (40μm for emergency use only). Lubricated air (ISO VG32) extends seal life by 30%.
Avoid mounting near high-frequency inverters (>10kHz). Allow 15-minute cooldown after 50,000 cycles in high-temp environments.
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
AirTAC 3V100 Series Solenoid Valve 3V11006NOBI Technical Details
- Model Identification: 3V11006NOBI
- Valve Configuration: 3/2-way normally open (direct-acting)
- Port Thread Standard: PT1/8" (G1/8 optional)
- Pressure Range: 0.05–1.0 MPa (minimum operating differential 0.02 MPa)
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow Capacity: 120L/min (at 0.5MPa)
- Body Material: Reinforced PBT resin with fiberglass
- Seal Compounds: High-grade NBR (standard), optional FKM for chemical resistance
- Ambient Temperature: -5℃ to 80℃ (non-freezing conditions)
- Duty Cycle: Continuous operation capable (100% ED)
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Electrical Protection: Class F insulation, surge protection diode integrated
- Weight: 185g ±5g (with connector)
- Dimensions: 53mm (L) × 34mm (W) × 65mm (H) (excluding fittings)
- Port Spacing: 13mm between inlet/outlet centers
- IP Rating: IP67 (coil protection)
- Compliance: RoHS 3, REACH SVHC
High-speed direct-operated valve featuring zero pressure start capability and manual override function. The encapsulated coil design ensures dust/water resistance for harsh environments. Optimized flow path geometry reduces pressure drop by 18% compared to previous generation models.
Industrial Implementation Scenarios:
- High-cycle pneumatic stamping press controls
- Beverage filling line volumetric control
- Textile machinery tensioning systems
- Semiconductor wafer handling robotics
- Electric vehicle battery cooling systems
Operational Guidance:
Requires 5-7μm filtration (40μm for emergency use only). Lubricated air (ISO VG32) extends seal life by 30%.
Avoid mounting near high-frequency inverters (>10kHz). Allow 15-minute cooldown after 50,000 cycles in high-temp environments.
| Property | Property Value |
|---|---|
| sku | 3V11006NOBI |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
