Airtac 3V200 Solenoid Valve 3V210-06NC-A
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V210-06NC-A Solenoid Valve Technical Details
- Model Series: 3V200 (Direct-Acting Series)
- Specific Model: 3V210-06NC-A
- Valve Configuration: 3-way, 2-position (3/2)
- Operation Type: Normally closed, pilot-operated
- Port Thread: PT1/8 (BSPP) with M5 sub-port option
- Effective Section Area: 18mm²
- Pressure Range: 0.15-0.8 MPa (21.7-116 PSI)
- Max Operating Frequency: 5 cycles/second
- Voltage Variations: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Coil Insulation: Class B (130℃)
- Ambient Temperature: -5℃ to 60℃ (with NBR seals)
- Fluid Temperature: 0-60℃
- Vibration Resistance: ≤55Hz with 1.5mm amplitude
- Shock Resistance: 100m/s² (approx. 10G) in 3 axes
- Body Material: Die-cast aluminum alloy (anodized)
- Spool Material: Stainless steel SUS304
- Seal Type: Double-lip NBR with dust wiper
- Manual Override: Optional (side-mounted lever)
- Weight: 180g ±5g (without fittings)
- Dimensions: 53mm (L) × 34mm (W) × 64mm (H)
- Mounting: ISO 4400 standard footprint
- Response Time: 15ms (energize), 20ms (de-energize)
- Power Consumption: 1.6W (DC), 3.2VA (AC)
- Protection Class: IP65 (coil), IP40 (valve body)
This pilot-operated solenoid valve features zero-pressure start capability and low power consumption design. The pressure-balanced poppet structure ensures reliable operation even with fluctuating supply pressures. Gold-plated terminals enhance electrical connectivity in humid environments. Compatible with ISO VG32 hydraulic oil mist lubrication.
- Plastic injection molding machine ejectors
- CNC tool changers and spindle brakes
- Beverage filling line pneumatic actuators
- Textile machinery tension control systems
- Semiconductor wafer handling robots
Operational Precautions:
- Install upstream air dryer when humidity exceeds 80% RH
- Use surge suppressor for AC coils exceeding 10W
- Allow 30-second cooldown after continuous 2-hour operation
- Lubricate spool monthly with ISO VG32 oil if used in dry air systems
| Property | Property Value |
|---|---|
| sku | 3V210-06NC-A |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
