Airtac 3V200 Solenoid Valve 3V21006NC-X0
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200-06NC-X0 Solenoid Valve Specifications
- Model: 3V210-06NC-X0 (3V200 series)
- Type: 3/2-way normally closed, pilot-operated
- Port type: G1/8 (ISO228/1 standard)
- Thread options: BSPP/NPTF
- Operating pressure: 0.05–1.0 MPa (optimized for 0.2–0.8 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.2W (DC), 2.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Flow coefficient (Cv): 0.65
- Max operating frequency: 5Hz
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Body material: Anodized aluminum alloy (corrosion-resistant)
- Temperature range: -5℃ to 80℃ (with intermittent peaks up to 100℃ for ≤5 mins)
- Protection rating: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A (standard) with flying lead option
- Weight: 220g ±5g (including connector)
- Dimensions: 54mm(L) × 38mm(W) × 72mm(H) (excluding fittings)
- Port spacing: 16mm (center-to-center)
High-performance pilot-operated solenoid valve featuring ultra-low power consumption and enhanced flow dynamics. The hardened aluminum body with multi-stage surface treatment ensures durability in humid/vibratory environments. Includes manual override and status LED (selectable models). Requires ISO 8573-1:2010 Class 3.4.3 compressed air (max 5mg/m³ oil content).
- High-cycle pneumatic presses (die casting machines)
- Beverage filling line actuator control
- Lithium battery production equipment
- Railway braking system test benches
- Photovoltaic panel cleaning robots
Installation protocol:
Mount with vibration-damping gaskets in high-G environments.
For horizontal mounting, orient coil upward ≥30° from vertical axis.
Lubricate seals with PAG oil (ISO VG32) during maintenance.
Replace desiccant in air prep unit every 800 operating hours.
| Property | Property Value |
|---|---|
| sku | 3V21006NC-X0 |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
