Airtac 3V200 Solenoid Valve 3V21006NCB
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series 3V210-06NCB Solenoid Valve Technical Details
- Full model designation: 3V210-06NCB (3V200 platform)
- Valve configuration: 3-port/2-position normally closed
- Actuation type: Pilot-operated with manual override option
- Port thread standard: G1/8 (BSPP) or optional NPT1/8
- Effective bore diameter: 2.5mm (Cv value 0.45)
- Pressure range: 0.05-1.0 MPa (minimum operating differential pressure 0.02 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Ambient temperature: -5℃ to 60℃ (no freeze condensation)
- Fluid temperature: 0-60℃
- Seal material: HNBR (Hydrogenated Nitrile) for improved chemical resistance
- Body material: Die-cast aluminum with anodized finish
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 1.6W (DC), 2.2VA (AC)
- Protection class: IP65 (coil), IP40 (valve body)
- Weight: 190g ±5g (excluding accessories)
- Dimensions: 54mm (L) × 34mm (W) × 63mm (H)
- Mounting orientation: Any (ISO 15407-1 compliant)
This pilot-operated solenoid valve features a unique "bubble-tight" shut-off design with dual-seal construction, achieving ≤0.1 mL/min internal leakage. The copper-free aluminum body prevents spark risks in explosive environments. Optimized flow path geometry reduces pressure drop by 18% compared to previous generations.
- Plastic injection molding machine nozzle control
- CNC tool changer pneumatic sequencing
- Food-grade CO₂ dispensing systems
- Lithium battery production dry room environments
- Semiconductor wafer handling vacuum break
Operational advisory:
Requires 5-10μm filtration (40μm for emergency use). For pulsation-sensitive applications,
install a 1.5L capacity surge tank ≤300mm downstream. Lubricated air operation extends
service interval by 30% - apply ISO VG32 turbine oil at 1 drip/5m³.
| Property | Property Value |
|---|---|
| sku | 3V21006NCB |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
