Airtac 3V200 Solenoid Valve 3V21006NCB-W
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NCB-W Technical Details
- Full model code: 3V21006NCB-W
- Valve type: 3/2-way normally closed (Pilot-operated)
- Port thread: G1/8 (BSPP) with NPT optional
- Effective area: 17.5mm² (pilot orifice)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage tolerance: ±10% (DC24V/AC110V/AC220V variants)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Fluid temperature: 0-60℃
- Seal material: Heat-resistant NBR (+5℃ margin vs standard)
- Body material: Reinforced PBT with brass core
- Port alignment: 3-port manifold design (IN/OUT/AUX)
- Weight: 280g ±5% (with coil)
- Dimensions: 56mm(L) × 34mm(W) × 72mm(H)
- Protection: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (at rated conditions)
High-flow pilot-operated solenoid valve optimized for industrial automation systems requiring rapid cycling. Features dual-chamber pressure balancing for consistent operation under variable loads. The brass-PBT composite construction resists chemical corrosion from synthetic lubricants and humid environments. Includes manual override button for system debugging.
- High-speed packaging line diverters (20-60 cycles/min)
- CNC machine tool clamp sequencing
- Beverage filling systems with CIP cleaning
- Plastic injection molding ejectors
- Railway brake air control modules
Installation protocol:
Mount in vibration-free location using M4 mounting screws (max torque 1.2N·m).
Always install downstream filter (5-40μm) and lubricator if using non-lubricated air.
Allow 15mm clearance above valve for manual override access.
| Property | Property Value |
|---|---|
| sku | 3V21006NCB-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
