AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W)
The AirTAC AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V210
About the AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W)
The 3V21006NCBG-W is a genuine AirTAC 3/2 solenoid valve, normally closed, with a 1/8in PT port. A 3/2 valve carries three ports - supply, outlet and exhaust - and two states: when the coil is energised it passes air from supply to outlet, and when it drops out it closes the supply and vents the outlet to exhaust. Normally closed means the outlet receives no air until the DC24V coil is powered, which is the behaviour you want behind a spring-return actuator that must release on power loss.
The DC24V coil suits a low-voltage control circuit, and the DIN plug entry means the valve takes a plug-in connector rather than flying leads. Across the 3V2 family AirTAC also offers normally open variants, AC220V, AC110V, AC24V and DC12V coils, flying-lead entry, and 3V200M manifold bases for mounting several valves on one shared supply. Published flow and power figures for this series are not in our hands, so send us your application and we will confirm the datasheet data you need.
AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W) Technical Specifications
| Model | AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W) |
|---|---|
| Series | 3V210 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | G (BSPP parallel) |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W)
| 3V210 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| G (BSPP parallel) | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W) Is Used
Packaging jaw blow-off
Switching a burst of shop air across a sealing jaw on a horizontal bagger to clear film and dust between cycles.
Fixture clamping
Feeding a spring-return clamp on a machining fixture, so the clamp only grips while the DC24V circuit holds the valve open.
Piloting a process valve
Sending a pilot signal to a larger diaphragm or angle-seat valve on a bottling line, opening and closing it from the control panel.
Is the AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W) the Right Part?
Choose NC when the actuator must sit still or vent on power loss; NO is the opposite and both exist in this family. The 1/8in port is the step above M5 and below 1/4in - a larger port suits a larger single-acting actuator, so step up rather than stretching one valve. Keep the coil voltage matched to the panel: this SKU is DC24V and a coil cannot be rewired to another voltage, so order the suffix you need. The DIN plug keeps wiring serviceable at the socket; flying-lead variants exist for hard-wired installs. If several valves share one station, a 3V200M manifold base carries them all on a single air feed and one wiring run. Because we do not hold flow figures for this family, ask us to size the valve against your actuator before you order - and if you want published flow and coil power in hand today, the 3V2 and 3V3 bodies carry those figures in their documentation. Need to drive a double-acting cylinder? That takes a 5-port valve from the AirTAC 4V range.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V210-06 Solenoid Valve, 3V200 Series (3V21006NCBG-W) FAQ
We do not carry published pressure, flow or coil-power figures for the 3V2 family in our own records. Tell us your supply conditions and actuator, and we will confirm the datasheet figures for this exact SKU by RFQ. If you need documented numbers immediately, the AirTAC 3V2 and 3V3 valve bodies have published flow and coil-power data.
Normally closed means the 1/8in outlet stays vented until the DC24V coil is energised, and returns to vent the moment power drops. That is the usual choice for spring-return cylinders, clamps and blow lines that must go safe on power loss.
