Airtac 3V200 Solenoid Valve 3V21006NCBI
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V210-06NC-BI Solenoid Valve Specifications
- Full model code: 3V21006NCBI (3V210-06NC-BI)
- Valve type: 3V200 series, 3/2-way normally closed
- Operation method: Pilot-operated with manual override
- Port thread: G1/8 (ISO228 standard) with BSPP connection
- Effective area: 18mm²
- Pressure range: 0.1-1.0 MPa (14.5-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Response time: ≤15ms (open), ≤20ms (close)
- Flow rate: 750 l/min (Cv=1.2 at 0.5MPa)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Viscosity range: 1-20 cSt
- Seal material: Heat-resistant NBR (Nitrile) + PBT coil housing
- Weight: 182g ±3g (including coil)
- Dimensions: 54mm(L) × 35mm(W) × 68mm(H)
- Protection: IP67 (coil), IP40 (valve body)
- Certifications: CE, RoHS, REACH compliant
The 3V21006NCBI features a dual-chamber pilot structure for reliable switching under variable pressure conditions. Its copper-free aluminum alloy body with hard anodizing resists chemical corrosion, while the reinforced solenoid coil withstands voltage fluctuations. The valve incorporates a dust-tight plunger design for operation in ISO 8573-1:2010 Class 4 air quality environments.
- Sequential control in semiconductor wafer handling robots
- Pneumatic clamping systems for CNC machining centers
- Vacuum generator switching in automated packaging lines
- Coolant flow control in laser cutting machines
- Breathing air systems for diving equipment manufacturing
Operational guidelines:
Maintain 0.3-1.0 MPa lubrication pressure when using oil-mist lubrication.
For horizontal installation, use model suffix "-H". Cycle frequency should not exceed 5Hz
without external heat dissipation. Replace seals every 5 million cycles in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | 3V21006NCBI |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
