Airtac 3V200 Solenoid Valve 3V21006NCBI-W
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NCBI-W Technical Details
- Full model code: 3V21006NCBI-W (3V200 platform)
- Valve configuration: 3/2-way normally closed (pilot-operated)
- Port threading: PT1/8" (G1/8 optional, specify when ordering)
- Pressure range: 0.15–0.85 MPa (21–123 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 0.53 (Kv 0.45) at 0.5 MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: High-grade NBR (Nitrile), optional Fluorocarbon (FKM) for -20℃~150℃
- Ambient temperature: -20℃ to 80℃ (with NBR seals)
- Coil insulation: Class F (155℃)
- Protection class: IP67 (dust/immersion protected)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 185g ±5g (without accessories)
- Dimensions: 52mm(L) × 40mm(W) × 70mm(H) (excluding connectors)
- Service life: ≥10 million cycles (at rated conditions)
High-flow compact solenoid valve featuring brass body with anodized aluminum core for corrosion resistance in humid environments. The pilot-operated design enables reliable operation under low pressure differential (minimum 0.15MPa). Integrated surge protection circuitry prevents coil burnout. Requires ISO 8573-1:2010 Class 4 compressed air (max 5mg/m³ oil content).
- High-speed pneumatic presses (stamping/bending machines)
- Bottle blowing machine air path control
- Automated assembly line clamping systems
- Textile machinery thread tension control
- Semiconductor wafer handling vacuum/pressure switching
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (torque ≤0.8N·m).
For horizontal installation, orient exhaust port downward.
Lubricate with ISO VG32 turbine oil if using dry air supply.
| Property | Property Value |
|---|---|
| sku | 3V21006NCBI-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
