Airtac 3V200 Solenoid Valve 3V21006NCC
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NCC Technical Specifications
- Model: 3V21006NCC (Full model code: 3V200-06-N-C-C)
- Valve type: 3/2-way, Normally Closed (Pilot-Operated)
- Port configuration: 1/4" BSPP (G1/4) with optional NPT threads
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 1.8 (Kv 1.56) at 0.5 MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 230g ±5% (with coil)
- Dimensions: 50mm(L) × 35mm(W) × 67mm(H)
- Seal materials: Main seal-NBR, auxiliary seals-FKM
- Temperature range: -5℃ to 80℃ (with 0℃ anti-freeze measures)
- Power consumption: 2.2W (AC), 2.6W (DC)
- Protection class: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599-1 standard compliant
High-flow solenoid valve with industrial-grade durability, featuring an optimized magnetic circuit design for 30% faster response than standard models. The copper-free aluminum alloy body with electrophoretic coating resists chemical corrosion and particulate abrasion. Designed for systems requiring rapid cycling (up to 5Hz) and compatible with ISO VG32 hydraulic oils in hybrid applications.
- CNC machine tool coolant control systems
- Plastic injection molding machine hydraulics
- Automated assembly line clamping mechanisms
- Semiconductor manufacturing gas control
- Electric vehicle battery cooling systems
Operational guidelines:
Maintain ≤85% relative humidity during operation. For horizontal installation,
use support bracket ATA-M3. Lubricate with ISO VG32 oil if pneumatic fluid
contains less than 1mg/m³ lubricant. Minimum 5-second purge cycle required
after 30 days of storage.
| Property | Property Value |
|---|---|
| sku | 3V21006NCC |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC 110V |
