Airtac 3V200 Solenoid Valve 3V21006NCEI
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V210-06NCEI Solenoid Valve Technical Details
- Full Model: 3V200-06NCEI (Series 3V200, variant 06NCEI)
- Valve Type: 3-way, 2-position normally closed (Direct-acting)
- Port Thread: PT1/8 (G1/8 optional)
- Pressure Range: 0.05–1.0 MPa (Extended range for low-pressure systems)
- Voltage Specifications:
- DC: 12V ±10%, 24V ±10%
- AC: 110V ±10% (50/60Hz), 220V ±10% (50/60Hz)
- Flow Capacity: 0.72 Cv (Kv 0.63) @ 0.5MPa
- Response Time: ≤15ms (Activation/deactivation)
- Weight: 230g ±5g (Including DIN connector)
- Dimensions: 54mm(L) × 40mm(W) × 70mm(H) (Body only, excl. fittings)
- Seal Materials: HNBR rubber (Hydrogenated Nitrile for oil resistance)
- Ambient Temperature: -10℃ to 80℃ (Wider thermal tolerance)
- Power Consumption: 2.2W (AC), 1.6W (DC)
- Protection Class: IP67 (Submersible up to 1m for 30min)
- Electrical Connection: DIN43650 Form A (Standard industrial connector)
High-performance pilotless solenoid valve optimized for fast cycling applications. Features copper-free aluminum alloy body with anodized coating for chemical resistance. Integrated surge suppression protects coils from voltage spikes. Compatible with ISO 8573-1:2010 Class 3 compressed air (max particle size 5μm).
- High-speed pick-and-place robotics (≥5Hz cycle rate)
- CNC machine tool clamping systems
- Food processing pneumatic circuits (FDA-compliant seals)
- Wastewater treatment plant actuators
- Electric vehicle battery cooling systems
Operational Guidance:
For optimal performance, install with inlet port (P) facing downward in dusty environments.
Requires minimum 10VDC holding voltage after initial 20ms 24VDC pulse start.
Lubricate every 5 million cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 3V21006NCEI |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC24V |
