Airtac 3V200 Solenoid Valve 3V21006NCF
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NCF Technical Details
- Model: 3V21006NCF (Full designation: 3V200-06-NC-F)
- Valve type: 3/2-way normally closed (direct-acting)
- Port thread: G1/8 (BSPP) with NPT1/8 adapter optional
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 1.8W | AC: 2.5VA
- Maximum flow rate: 750 l/min (Cv=1.3 at 0.5MPa)
- Response time: ≤15ms (energize) / ≤20ms (de-energize)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Fluid temperature: 0-60℃ (lubricated air recommended)
- Seal material: Heat-resistant NBR (Nitrile)
- Body material: Reinforced PBT with copper-free aluminum alloy
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 185g ±5g (excluding connectors)
- Dimensions: 53mm(L) × 34mm(W) × 68mm(H) (manual override adds 8mm)
High-cycle industrial solenoid valve with direct-acting poppet structure for reliable operation in low-pressure systems. Features zero pressure differential startup capability and LED status indicator (F suffix models). Compatible with vacuum applications when using special seals (optional).
- Textile machinery tension control systems
- Semiconductor wafer handling robots
- Electric vehicle battery cooling circuits
- 3D printer pneumatic extruders
- Beverage filling line emergency shutoffs
Installation requirements:
Use vibration-damping mounts in high-shock environments. Lubricate with ISO VG32
turbine oil if operating below 0.3MPa. Minimum 12V DC required for cold start (-5℃).
- FKM seals kit (for chemical resistance)
- DIN43650 Form C coil connector
- Surge suppressor module (for AC models)
| Property | Property Value |
|---|---|
| sku | 3V21006NCF |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC12V |
