Airtac 3V200 Solenoid Valve 3V21006NOB-W
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NOB-W Technical Details
- Model: 3V21006NOB-W (Full designation)
- Valve type: 3/2-way normally open (Pilot-operated)
- Port configuration: 1/4" BSPP (G1/4) with M5 sub-port option
- Pressure range: 0.15–0.85 MPa (21.7–123.3 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (Cv=1.2) at 0.5 MPa
- Weight: 180g ±5% (without connector)
- Dimensions: 58mm(L) × 34mm(W) × 64mm(H) (body only)
- Seal materials: HNBR main seals with FKM secondary wipers
- Temperature tolerance: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC) / 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection class: IP67 (dust/water resistant)
- Cycle life: ≥10 million operations
High-flow industrial solenoid valve with anti-vibration design, featuring brass body with nickel plating for corrosion resistance. The pilot-operated mechanism enables reliable switching under variable pressure conditions. Requires ISO 8573-1 class 3 compressed air (40μm filtration recommended). Includes manual override for system debugging.
- CNC machine tool pneumatic systems
- Plastic injection molding machines
- Automated assembly line actuators
- Textile machinery air control
- Food processing equipment (oil-resistant version available)
Mounting requirements:
Install with 15° angular tolerance from vertical position. Maintain minimum
50mm clearance below valve for condensate drainage. Use shock-absorbing
brackets in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 3V21006NOB-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
