Airtac 3V200 Solenoid Valve 3V21006NOBI
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200-06NO-BI Solenoid Valve Specifications
- Model: 3V210-06NO-BI (3V21006NOBI)
- Type: 3/2-way normally open (pilot-operated)
- Port size: PT1/8 (G1/8 or NPT1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 0.85
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 185g ±5g
- Dimensions: 52mm(L) × 35mm(W) × 68mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (with no ice formation)
- Power consumption: DC: 2.5W max | AC: 3.5VA max
- Protection rating: IP67 (dust tight and protected against temporary immersion)
- Port thread depth: 10mm (minimum engagement 7 threads)
High-flow pilot-operated solenoid valve with fail-safe open design, featuring dual-position memory function for stable pressure holding. The brass body with electroless nickel plating ensures corrosion resistance in humid environments. Optimized for systems requiring rapid cycling (up to 5Hz) and compatible with ISO 1-5 pneumatic symbols.
- Plastic injection molding machine ejectors
- CNC tool changers and spindle brakes
- Food processing pneumatic actuators (FDA-compliant versions available)
- Automated assembly line clamping systems
- Semiconductor wafer handling equipment
Installation note:
For horizontal mounting, use anti-vibration brackets. Lubricate with ISO VG32 turbine oil
if operating below -5℃. Always install downstream filter regulator (5-40μm) with auto-drain.
Critical notice:
Not compatible with phosphate ester-based fluids. Maximum allowable
momentary pressure surge: 1.2MPa (174PSI) for ≤100ms.
| Property | Property Value |
|---|---|
| sku | 3V21006NOBI |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
