Airtac 3V200 Solenoid Valve 3V21006NOBI-W
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NOBI-W Technical Specifications
- Model: 3V21006NOBI-W (Full designation code)
- Valve type: 3/2-way normally open (Direct-acting with manual override)
- Port configuration: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC) / 3.2VA (AC)
- Response time: ≤15ms (open/close cycle)
- Seal material: Fluorocarbon rubber (FKM) for chemical resistance
- Ambient temperature: -10℃ to 60℃ (14℉ to 140℉)
- Fluid temperature: 0℃ to 60℃ (32℉ to 140℉)
- Protection class: IP67 (Dust-tight and protected against immersion)
- Weight: 210g ±5g (including connector)
- Dimensions: 54mm(L) × 36mm(W) × 65mm(H) (Body only, excluding fittings)
- Port thread depth: 9.5mm (minimum engagement)
- Max flow rate: 750 L/min (ANR, at 0.5MPa)
- Hysteresis: ≤0.02MPa (Pressure differential requirement)
High-performance industrial solenoid valve featuring brass body construction with PPS coil housing for enhanced durability in harsh environments. The manual override allows emergency operation during power failures. Optimized flow path design reduces pressure drop by 18% compared to previous generations. Requires 5μm filtration (with auto-drain) for maximum service life.
- Plastic injection molding machine sequence control
- CNC tool changers and spindle cooling systems
- Food processing equipment (FDA-compliant seals)
- Semiconductor wafer handling robotics
- Wastewater treatment pneumatic actuators
- Electric vehicle battery cooling systems
Installation guidelines:
Mount in vibration-free position using M4 mounting screws (max torque 1.2N·m).
For horizontal piping, orient coil upward to prevent debris accumulation.
Perform monthly manual cycling to maintain seal elasticity.
| Property | Property Value |
|---|---|
| sku | 3V21006NOBI-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
