Airtac 3V200 Solenoid Valve 3V21006NOC
2. Spool-type structure with excellent sealing properties and high responsiveness;
3. Dual-coil design features memory function (position retention upon power loss);
4. Precision-engineered internal bore reduces friction resistance, enables low activation pressure (0.15MPa) and ensures extended service life;
5. Lubrication-free operation;
6. Integrated manual override for simplified commissioning and maintenance;
7. Multiple standardized voltage options available;
8. Modular valve system compatibility with manifold bases for space-optimized installations.
Category: Solenoid Valves | Brand: AirTAC | Series: 3V200
AirTAC 3V200 Series Solenoid Valve 3V21006NOC Technical Details
- Full Model Code: 3V210-06NOC (with manual override)
- Valve Type: 3/2-way normally closed, direct-acting
- Thread Standard: G1/8 (ISO228) with BSPP port
- Operating Pressure Range: 0.1-1.0 MPa (14.5-145 PSI)
- Voltage Variations: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Flow Capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Seal Material: Heat-resistant NBR (Nitrile) - Vaneer 70
- Ambient Temperature: -5℃ to 80℃ (with 0.5MPa minimum at extremes)
- Coil Insulation: Class F (155℃)
- Protection Grade: IP67 (dustproof & temporary immersion)
- Electrical Connection: DIN43650 Form A (standard), optional terminal box
- Weight: 220g ±5% (with coil)
- Dimensions: 54mm(L) × 40mm(W) × 67mm(H) (excluding fittings)
High-flow solenoid valve with manual override lever, featuring brass main body with electroless nickel plating for corrosion resistance. The low-hysteresis design ensures precise airflow control in vacuum and pressure applications. Includes surge suppression circuit for extended coil life. Requires 5μm filtration (40μm max) with lubricant-free air. Meets ISO 5599-1 dimensional standards for modular assembly.
- Plastic injection molding machine ejectors
- CNC pneumatic tool changers
- Industrial dishwasher door lock systems
- Textile machinery air-jet looms
- Beverage filling line pneumatic actuators
- Semiconductor wafer handling robots
Maintenance Tip:
For continuous operation, install in horizontal position with exhaust port downward.
Use locknuts with 14-18 N·m torque. Cycle valve monthly if idle to prevent seal hardening.
| Property | Property Value |
|---|---|
| sku | 3V21006NOC |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC 110V |
