Airtac 3V200 Solenoid Valve 3V220-06-A
The AirTAC Airtac 3V200 Solenoid Valve 3V220-06-A is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Series3V220
About the Airtac 3V200 Solenoid Valve 3V220-06-A
Three ports, two positions, one moving stream of air: that is what 3/2 means. Supply, outlet and exhaust, and the valve either connects supply to outlet or vents the outlet. This 3V220-06-A carries a 1/8in PT port and an AC220V coil, a combination that drops straight into a standard single-phase control panel and feeds compact spring-return actuators.
Genuine AirTAC, and far from the only configuration: the family also covers the normally closed and normally open versions, four other coil voltages, flying-lead wiring for panels that prefer pre-wired coils, and 3V manifold bases that carry several valves on one shared air supply. Datasheet figures such as flow, pressure range and coil power are confirmed by us on request rather than guessed here.
Airtac 3V200 Solenoid Valve 3V220-06-A Technical Specifications
| Model | Airtac 3V200 Solenoid Valve 3V220-06-A |
|---|---|
| Series | 3V220 |
| Valve type | 3/2-way (3-port, 2-position) |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V200 Solenoid Valve 3V220-06-A
| 3V220 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V200 Solenoid Valve 3V220-06-A Is Used
Pick-and-place gripper
Feed a spring-open mini gripper on a small robot cell; the 1/8in port matches the gripper's compact air line, and the AC220V coil connects to the cell's mains control circuit.
Electronics test bench
Turn one air line on and off for a pneumatic actuator that presses a connector into a test fixture, under command of the bench controls.
Bottling hold-down
Clamp a container under the filler nozzle on a bottling line; the single-acting hold-down cylinder retracts on spring power the moment the valve vents.
Is the Airtac 3V200 Solenoid Valve 3V220-06-A the Right Part?
The code gives you a 1/8in PT port and an AC220V coil, which suits a standard mains-wired control panel. It does not encode the state, so tell us whether you need normally closed (outlet vented until energised) or normally open (outlet fed until energised) when you order. Step the port up to 1/4in if the spring-return actuator is bigger than a hand-size clamp; M5 exists for very small pilot lines. DIN plug entry is the configuration this code defines - flying leads (suffix I) exist across the family if pre-wired is preferred, and filtered air should always reach a solenoid valve. We hold no published flow figures for this family, so ask us to check the valve against your actuator; the separately documented 3V2 06 and 3V3 pages do carry published flow and coil power figures if you need them now. Double-acting cylinders need a 4V 5-port valve instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V200 Solenoid Valve 3V220-06-A FAQ
This code does not carry a state suffix, so confirm NC or NO when ordering. Choose NC when a power or air loss must leave the outlet vented and the actuator at rest; choose NO when the process must keep receiving air through a failure. Both versions exist in this family.
Not from this page - we confirm all three from the manufacturer datasheet once you send an RFQ, and we would rather do that than publish a number we cannot stand behind. If you need documented figures today, look at the separately documented 3V2 06/08 and 3V3 valve pages, where flow and coil power are published.
