Airtac 3V300 Solenoid Valve 3V310-10NC-A
The AirTAC Airtac 3V300 Solenoid Valve 3V310-10NC-A is a genuine 3-port 2-position (3/2) solenoid valve with 3/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size3/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Series3V310
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 3V300 Solenoid Valve 3V310-10NC-A
A 3/2 valve has one job: connect the supply to the outlet, or connect the outlet to exhaust. The 3V310-10NC does that on the largest port in this kit, 3/8in PT, in a normally closed state, so the outlet is dead until the coil is energised and vents the moment power is lost - a natural fit where a spring-return actuator must release on failure.
It is a genuine AirTAC part with an AC220V coil on a DIN plug. The 3V1, 3V2 and 3V3 family also covers NO states, five coil voltages from DC12V to AC220V, flying-lead entry, and 3V-F manifold bases from 1 to 20 stations. Datasheet figures for pressure and flow are confirmed on request.
Airtac 3V300 Solenoid Valve 3V310-10NC-A Technical Specifications
| Model | Airtac 3V300 Solenoid Valve 3V310-10NC-A |
|---|---|
| Series | 3V310 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 3/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V300 Solenoid Valve 3V310-10NC-A
| 3V310 | Body. |
|---|---|
| 3/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V300 Solenoid Valve 3V310-10NC-A Is Used
Scissor table lift
A single-acting cylinder on a small scissor-lift table, where the platform lowers under spring force as soon as the valve vents the outlet.
Press line stopper
A spring-retract pallet stop on a stamping press line, held out only while the control circuit keeps the coil energised.
Weld fixture clamp
A clamp on a welding fixture that must open the moment control power fails, leaving the part free for the operator.
Is the Airtac 3V300 Solenoid Valve 3V310-10NC-A the Right Part?
Choose NC when power loss must vent the actuator, NO when it must stay fed; this SKU is the NC choice in the family's largest port, 3/8in PT, which suits bigger spring-return cylinders than the 1/4in or 1/8in bodies. If one valve is not enough, a 3V300M manifold base carries several valves on a single air supply. Published flow for this group is not in our hands, so let us verify the size against your actuator by RFQ; buyers who need printed figures now can use the separately documented 3V2 and 3V3 port-coded bodies, and a double-acting cylinder calls for the 5-port AirTAC 4V series instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V300 Solenoid Valve 3V310-10NC-A FAQ
Yes - raise an RFQ and we will pull operating pressure, flow and coil power from the AirTAC datasheet and reply in writing. For a product page with those numbers already printed, compare the separately documented 3V2 and 3V3 port-coded bodies.
Decide what must happen at power loss. NC vents the outlet when de-energised, which suits a cylinder that must retract or a jet that must stay off. NO feeds the outlet until energised, which suits a hold-on function. Both states exist across the 3V1, 3V2 and 3V3 family.
