Airtac 3V300 Solenoid Valve 3V31008NCB
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCB Technical Details
- Full model designation: 3V310-08NCB (3V300 platform)
- Valve configuration: 3/2-way normally closed (pilot-operated)
- Port connection: PT3/8 (G3/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 1.2 (Kv 1.4) at 0.5 MPa
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 320g ±5% (without connector)
- Dimensions: 60mm(L) × 45mm(W) × 85mm(H) (manual override adds 12mm)
- Seal materials: NBR standard (Viton/FKM optional)
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Coil insulation class: Class F (155℃)
- Power consumption: ≤3.5W (AC), ≤3.8W (DC)
- Protection standard: IP67 (dust/water resistant)
- Cycle life: ≥10 million operations
High-flow solenoid valve engineered for industrial automation systems requiring rapid cycling and reliable shut-off. Features brass body with hard-anodized aluminum core for corrosion resistance in humid environments. The direct diaphragm structure ensures stable operation even with pressure fluctuations. Requires 5μm filtered dry air (ISO 8573-1:2010 Class 3.4.2) and regular lubrication (ISO VG32 turbine oil recommended).
- Pneumatic punching machines (press tool actuation)
- Plastic injection molding clamp systems
- Beverage canning line cylinder control
- Automotive wheel hub assembly stations
- Industrial dryer blast gate regulation
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance from adjacent components for heat dissipation.
Always install downstream moisture trap (40μm filter regulator).
| Property | Property Value |
|---|---|
| sku | 3V31008NCB |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
