AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W)
The AirTAC AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W) is a genuine 3-port 2-position (3/2) solenoid valve with 1/4 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/4 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V310
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W)
Three ports, two states: a 3/2 valve connects supply to outlet in one state and dumps the outlet to exhaust in the other. In the 3V31008NCB-W that switching happens through a 1/4in port, one step up from 1/8in, which is the size to reach for when a single-acting cylinder or clamp has enough volume that a smaller port would slow the cycle. The coil is DC24V, and normally closed behaviour applies: no air at the outlet until the coil is energised.
This is a genuine AirTAC part. The same family covers M5, 1/8in, 1/4in and 3/8in ports, NC and NO states, all five voltages, both electrical entries and shared-supply 3V-F bases. Pressure, flow and coil-power figures live on the datasheet - ask, and we will send them.
AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W) Technical Specifications
| Model | AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W) |
|---|---|
| Series | 3V310 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/4 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W)
| 3V310 | Body. |
|---|---|
| 1/4 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W) Is Used
Jig clamp on a welding fixture
A control signal energises the valve to clamp a panel into a welding jig; releasing the signal vents the line so the spring-return clamp opens and the welded part can be lifted out.
Pneumatic stopper on a conveyor
A spring-raised stopper blade on a packaging conveyor is held down by a single-acting cylinder. This valve feeds the cylinder to let cartons pass, and vents it to raise the stopper and halt the flow.
Threaded-part blow-down
After a tapping or assembly operation, energise the valve to blow machined chips and coolant residue out of a threaded housing before the part moves to inspection.
Is the AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W) the Right Part?
The port steps through M5, 1/8in, 1/4in and 3/8in across the family; at 1/4in this valve feeds bigger single-acting cylinders and clamps than the 1/8in bodies, and 3/8in exists if your actuator is larger still. NC gives you a vented, air-free outlet whenever the coil is off - the fail-safe direction for most clamping. DC24V is fixed at order time and must match the panel; DIN plug entry takes a field-fitted connector, and the default thread is PT with G and NPT available as options. If several valves on one machine could share a feed, a 3V-F manifold base consolidates supply and wiring and makes fault-finding simpler. We have no published flow figure for this family in hand, so let us confirm the size against your actuator via RFQ; the documented 3V2 and 3V3 bodies publish flow and coil power now, and the 4V series is the answer for double-acting cylinders.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V310-08 Solenoid Valve, 3V300 Series (3V31008NCB-W) FAQ
Ask what must happen when control power fails. Normally closed shuts the outlet and vents it, so a spring-return cylinder relaxes - usually the safe direction for clamps. Normally open keeps air flowing when de-energised, for jobs where loss of signal must not stop the flow. Both states exist across this 3V family.
Not on this page - we hold no published figures for this family and will not estimate. Request the datasheet through the RFQ and we will confirm pressure, flow and coil power. The documented 3V2 (1/8in and 1/4in) and 3V3 (1/4in) bodies publish those figures if you need them right away.
