Airtac 3V300 Solenoid Valve 3V31008NCBI
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCBI Technical Details
- Model Code: 3V31008NCBI (Full designation: 3V300-08-NC-B-I)
- Valve Type: 5/3-way closed center (triple position)
- Operation Mode: Double solenoid with spring return
- Port Configuration: 8 ports (P, A, B, EA, EB, R1, R2, S)
- Port Thread: PT1/4 (G1/4 optional)
- Effective Sectional Area: 18mm²
- Operating Pressure: 0.05–1.0 MPa (7-145 PSI)
- Voltage Tolerance: ±10% (DC24V standard, AC options available)
- Coil Insulation: Class F (155℃ rated)
- Response Time: ≤35ms (pressurized to full flow)
- Ambient Temperature: -5℃ to 60℃ (anti-condensation design)
- Viscosity Range: ≤32 cSt (requires air lubricator below 10℃)
- Seal Material: Heat-resistant NBR (replaceable cartridge seals)
- Body Material: Anodized aluminum alloy (ISO 1-5 corrosion rating)
- Weight: 580g ±5% (including connectors)
- Dimensions: 110mm(L) × 54mm(W) × 45mm(H) (excluding fittings)
- Mounting: ISO 5599-1 standard interface
- Certifications: CE, RoHS, REACH compliant
High-flow mid-position closed valve designed for complex pneumatic circuits requiring neutral state pressure locking. Features dual manual overrides and LED status indicators. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality. Includes surge protection circuitry for extended coil life.
- Clamping sequence control in CNC tool changers
- Press brake dual cylinder synchronization systems
- Automated assembly line transfer units
- Plastic injection molding machine ejectors
- Test bench pressure cycling systems
Maintenance Protocol:
Perform seal replacement every 5 million cycles (minimum). Use torque wrench for port connections:
12-15 N·m for metal fittings, 8-10 N·m for plastic. Maintain 85% ≤ RH non-condensing environment.
| Property | Property Value |
|---|---|
| sku | 3V31008NCBI |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
