Airtac 3V300 Solenoid Valve 3V31008NCCI
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCCI Technical Details
- Model: 3V31008NCCI (3V300 platform)
- Valve type: 5/3-way closed center, double solenoid
- Port configuration: 8 mm nominal port size (PT1/4 NPT optional)
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 1,200 NL/min (ANR at 0.5 MPa)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Body material: Die-cast aluminum with chromate coating
- Weight: 680g ±5% (with coils)
- Dimensions: 56mm(W) × 100mm(L) × 72mm(H)
- Response time: ≤35ms (exhaust to actuation)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A with LED indicator
- Ambient temperature: -20℃ to +80℃ (non-freezing)
- Coil insulation class: Class F (155℃)
High-flow proportional control valve engineered for industrial automation sequences requiring mid-stroke positioning. Features zero-pressure start capability and surge protection circuitry. Optimized for vacuum applications (0.05 MPa minimum) with optional silencer accessories. Requires 5μm filtration with oil mist lubrication (ISO VG32 recommended).
- Plastic injection molding machine clamp control
- Automated assembly line positioning cylinders
- Textile machinery tensioning systems
- Die-casting machine core pull mechanisms
- Semiconductor wafer handling robots
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Maintain ≥20mm clearance below valve for condensate drainage.
Perform weekly manual override tests during maintenance cycles.
| Property | Property Value |
|---|---|
| sku | 3V31008NCCI |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC 110V |
