Airtac 3V300 Solenoid Valve 3V31008NCE
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NCE Technical Details
- Model: 3V31008NCE
- Valve type: 3-position 5-way (3V300 series)
- Operation mode: Double solenoid with spring return
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage specifications: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (including connectors)
- Dimensions: 52mm(L) × 38mm(W) × 78mm(H)
- Seal material: NBR (Nitrile) standard / Optional Viton (FKM)
- Ambient temperature range: -5℃ to 80℃ (with condensation prevention)
- Power consumption: 2.2W (DC24V), 3.5VA (AC models)
- Protection class: IP67 (dustproof & temporary immersion resistant)
- Response time: ≤10ms (excitation), ≤15ms (de-excitation)
- Port thread connection: Direct mounting (ISO 228 standard)
- Effective flow rate: 1000 l/min (ANR, at 0.5MPa)
High-flow directional control valve engineered for complex pneumatic circuits requiring mid-stroke positioning. Features twin coil design with manual override capability and surge suppression diodes. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Multi-axis pneumatic actuator control in assembly robots
- Plastic injection molding machine clamp mechanisms
- Automated conveyor sorting systems with position hold
- CNC machine tool chuck pressure regulation
- Beverage canning line pneumatic sequencing
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance around exhaust ports for proper venting.
Use copper-free anti-seize compound on threaded connections.
| Property | Property Value |
|---|---|
| sku | 3V31008NCE |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC24V |
