Airtac 3V300 Solenoid Valve 3V31008NOAI
2. Spool-type structure ensures excellent sealing performance and responsive operation;
3. Dual-solenoid version features memory function;
4. Precision honing process for inner bore enables reduced friction, low activation pressure, and extended service life;
5. Maintenance-free lubrication system eliminates oil replenishment;
6. Integrated manual override facilitates installation and commissioning;
7. Multiple standard voltage options for flexible integration;
8. Base manifold integration capability enables space-saving configuration.
Category: Solenoid Valves | Brand: Airtac | Series: 3V300
AirTAC 3V300 Series Solenoid Valve 3V31008NOAI Technical Details
- Full model designation: 3V310-08-NO-AI
- Valve type: 5-port 3-position (3V300 series) center closed
- Operation method: Single solenoid pilot-operated
- Port configuration: 1/4" BSPP (G1/4)
- Effective area ratio: 1:1.15
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC220V 50/60Hz
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Response time: ≤15ms (open), ≤20ms (close)
- Flow capacity: 850 l/min (Cv=1.2)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Body material: Reinforced PBT with glass fiber
- Protection class: IP67 (dust/water resistant)
- Weight: 350g ±5% (with connector)
- Dimensions: 65mm(L) × 50mm(W) × 80mm(H)
- Port thread depth: 10mm (minimum engagement)
High-flow proportional control valve designed for precision positioning systems requiring mid-position cutoff. Features dual-pressure balancing chambers for stable operation under variable loads. The anti-vibration coil design ensures reliability in mobile applications. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Paper converting equipment tension regulation
- Robotic welding positioners
- Beverage filling station emergency stop systems
Installation protocol:
Mount horizontally with manifold brackets (torque ≤1.5Nm). Maintain 15mm
clearance for heat dissipation. Use pulse-rated cables (AWG20-16) with
shielded connectors for EMI protection. Lubricate seals with ISO VG32
turbine oil if stored >6 months.
| Property | Property Value |
|---|---|
| sku | 3V31008NOAI |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
