Airtac ACKDR Rotary Cylinder ACKDR50X90
2. Triple guide groove structure delivers enhanced guiding precision;
3. Configurable with single-side and double-side (90°) operation modes;
4. Offers left-handed/right-handed rotation options with 90° or 180° angular strokes;
5. Heat-treated piston rod manufactured from special alloy steel guarantees prolonged service life.
Category: Angular Cylinders | Brand: AirTAC | Series: ACKDR
AirTAC ACKDR Rotary Clamp Cylinder ACKDR50X90 Technical Specifications
- Model: ACKDR50X90
- Bore size: Ø50 mm
- Stroke: 90 mm
- Rotation angle: 90° (±1° precision)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Foot-mounted with dual M8x1.25 mounting holes
- Port size: 1/4" NPT (G1/8 optional)
- Material: Aluminum alloy cylinder tube, chrome-plated piston rod
- Seal type: HNBR seals (oil & heat resistant)
- Weight: 3.2 kg ±5%
- Dimensions: 200mm(L) × 75mm(W) × 82mm(H)
- Repeat accuracy: ±0.5mm
- Max speed: 500 mm/s
- Air consumption: 16.5 L/min at 0.5 MPa
Compact 90° rotary-linear hybrid actuator combining vertical clamping with horizontal rotation. Features dual-guide rod stabilization for precision positioning in tight spaces. Anti-rotation design maintains orientation during stroke. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 3).
- PCB board flipping in electronics assembly
- Workpiece reorientation in CNC machine tending
- Palletizing systems with vertical stacking
- Automated welding fixture positioning
- Medical device component alignment
Installation recommendation:
Maintain 0.5-1mm clearance between rotating parts and adjacent surfaces.
Lubricate guide rods weekly with ISO VG32 pneumatic oil. Avoid side loads exceeding 50N.
| Property | Property Value |
|---|---|
| sku | ACKDR50X90 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <50mm> |
| Direction Code | Press-down Right-hand |
| Rotation Angle Code | <90°> |
