Airtac AirTAC 2KW Fluid Control Valve 2KW03006E
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW Series Fluid Control Valve 2KW03006E Technical Details
- Model: 2KW03006E
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Max flow rate: 1,200 L/min (Cv=2.0)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤25ms (excitation), ≤35ms (de-excitation)
- Weight: 0.95 kg (±3%)
- Dimensions: 130mm(L) × 52mm(W) × 65mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with center-block function, featuring dual manual override and LED status indicator. The hardened aluminum alloy body with chrome-plated brass spool ensures 2 million cycle durability. Designed for systems requiring intermediate position pressure holding, with surge suppression for shock-free switching.
- Plastic injection molding machine clamp units
- Automated assembly line positioning fixtures
- Textile machinery tension control systems
- Die casting machine ejector mechanisms
- Semiconductor wafer handling robots
Installation requirements:
Mount on ISO 5599/1 standard subplate (ADK-03P). Maintain ambient temperature
below 60℃ with 10mm clearance around manifold. Use 5μm filtration with
automatic drain. Lubrication: ISO VG32 turbine oil recommended.
| Property | Property Value |
|---|---|
| sku | 2KW03006E |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
