Airtac APB Straight Tee Fitting APB10-01
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB10-01 Standard Tee Fitting Specifications
- Model: APB10-01
- Type: Female threaded tee connector (straight type)
- Thread standard: BSPP (G) / NPT optional
- Port size: 1/8" (10mm nominal)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥3.0 MPa
- Material: Lead-free brass CW617N
- Surface treatment: Electroless nickel plating (5-8μm)
- Seal type: Integrated O-ring (NBR)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 22g ±0.5g
- Dimensions: 30mm(L) × 18mm(W) × 18mm(H)
- Thread engagement depth: 8mm
- Flow coefficient (Cv): 0.45
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined brass tee connector with triple sealing protection, featuring 360° rotatable ports for flexible piping arrangements. The electroless nickel coating provides enhanced corrosion resistance exceeding 96hrs salt spray test (ASTM B117). Designed for leak-free performance under pulsating pressure conditions.
- Branch line connections in pneumatic control systems
- Modular assembly in factory automation equipment
- Pressure gauge manifold installations
- Medical gas line distribution systems
- Robotic end-effector pneumatic networks
Installation protocol:
Apply 2-3 drops of silicone-based lubricant on threads before assembly.
Tighten with 12-15N·m torque using backup wrench to prevent port rotation.
Maximum angular misalignment tolerance: ±3° between connected components.
| Property | Property Value |
|---|---|
| sku | APB10-01 |
