Airtac APB Straight Tee Fitting APB10-02
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Straight Tee Connector APB10-02 Technical Details
- Model: APB10-02
- Type: Straight thread tee (ISO 6149 standard)
- Port configuration: 3-way T-shaped flow path
- Thread specifications: M10×1.0 female threads (all ports)
- Material: Lead-free brass (CuZn21Si3P) with electroless nickel plating
- Pressure rating: 0.05–1.0 MPa (operating), 1.5 MPa burst
- Temperature range: -20℃ to 80℃ (continuous use)
- Seal type: Embedded O-ring (NBR material)
- Surface roughness: Ra ≤1.6μm (internal flow paths)
- Weight: 18.5g ±0.3g
- Dimensions: 24mm(L) × 24mm(W) × 24mm(H) (body only)
- Torque limit: 3.5–4.5 N·m during installation
- Flow coefficient: Cv≈0.15
Precision-machined brass tee connector featuring triple-sealing design (metal-to-metal, thread sealant, and O-ring) for leak-free performance. The compact cubic form factor enables space-efficient manifold assemblies. Nickel plating provides corrosion resistance in humid environments while maintaining electrical conductivity for grounding purposes.
- Pneumatic circuit branching in automation equipment
- Modular manifold blocks for CNC machines
- Pressure gauge installation points
- Vacuum system distribution nodes
- Medical gas line distribution (oxygen/nitrogen)
Installation protocol:
Apply thread sealant to male fittings only. Clockwise rotation alignment mark
on hex flats assists in visual confirmation of proper engagement. Maximum
90° reorientation allowed after initial tightening.
| Property | Property Value |
|---|---|
| sku | APB10-02 |
