Airtac APB Straight Tee Fitting APB12-M20
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Straight Tee Connector APB12-M20 Full Specifications
- Model: APB12-M20
- Type: Straight thread tee connector (equal distribution)
- Thread standard: Metric fine thread M20×1.5 (ISO 6149 compliant)
- Port configuration: 3-way 1/4" BSPP female threads
- Material: Nickel-plated brass body (CuZn39Pb3)
- Seal type: Double O-ring design with NBR seals
- Pressure rating: 0.2-1.5 MPa (29-217 PSI)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Torque specification: 15-20 Nm installation torque
- Weight: 86g ±2g
- Dimensions: 38mm(L) × 32mm(W) × 32mm(H)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Compliance: RoHS 2011/65/EU compliant
Precision-engineered tee connector featuring triple-seal technology for leak-free pneumatic connections. The 60° angular port design enables compact plumbing layouts while maintaining optimal flow characteristics (CV value: 0.45). Anti-vibration threads prevent self-loosening in high-cycle applications.
- Modular pneumatic manifolds in assembly robots
- Plastic injection molding machine air circuits
- CNC tool changer pneumatic systems
- Food processing equipment (FDA-compliant grease option available)
- Railway braking system distribution nodes
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (taper threads only).
Use flank-seal technique - tighten until snug plus ¼ turn.
Maximum re-use cycles: 5 times with seal inspection.
- Effective cross-section: 7.8 mm²
- Flow coefficient (Cv): 0.43
- Pressure drop: ≤0.02 MPa at 500 NL/min flow rate
| Property | Property Value |
|---|---|
| sku | APB12-M20 |
