Airtac APB Straight Tee Fitting APB14-02
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Tee Connector APB14-02 Technical Details
- Model: APB14-02 (Straight Thread)
- Type: Equal tee with straight thread ports
- Thread standard: PT1/4 (BSPP)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Seal material: NBR (Nitrile) O-rings
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Weight: 23.5±0.5g
- Dimensions: 20.5mm (L) × 20.5mm (W) × 28.4mm (H)
- Surface roughness: Ra0.8μm (flow path)
- Leakage rate: <10 cm³/min at 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined brass tee connector featuring triple-port flow distribution with uniform internal bore geometry. The 60° angled branch port optimizes flow dynamics while maintaining compact dimensions. Nickel plating provides corrosion resistance in humid environments. Compatible with air, inert gases, and water-based fluids.
- Pneumatic circuit branching in automation equipment
- Coolant line distribution in CNC machining centers
- Vacuum system manifolds for pick-and-place robots
- Hydraulic test bench instrumentation setups
- Compressed air networks in food packaging lines
Installation protocol:
Apply 3-5Nm torque during assembly. Use thread sealant only on male threads.
Align flow arrows with primary direction. Pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APB14-02 |
