Airtac APB Straight Tee Fitting APB16-04
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Straight Tee Connector APB16-04 Technical Details
- Model: APB16-04
- Type: Straight thread-type tee connector (female threads)
- Thread standard: Metric (M5×0.8) & BSPP (G1/8") compatible
- Material: Nickel-plated brass (base), CRN rubber seals
- Max working pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 18.5g ±0.5g
- Dimensions: 19.8mm(L) × 16.2mm(W) × 16.2mm(H)
- Surface hardness: HV200-250
- Leakage rate: <0.1 mL/min under 0.5 MPa
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
Precision-engineered tee connector with dual-thread compatibility, featuring anti-vibration grooves and chemical-resistant seals. The hexagonal body design allows tool-free hand tightening while maintaining 360° rotational flexibility post-installation. Internal flow path optimized for minimal pressure drop (ΔP <0.02MPa @ 500L/min).
- Branching pneumatic circuits in SMC manifold systems
- PLC-controlled automation test benches
- Medical gas line distribution units
- Robotic end-effector air supply networks
- Compressed air monitoring sensor integration
Installation protocol:
Apply 2-3 drops of pneumatic sealant (viscosity 100-150mPa·s) on threads before assembly.
Tighten to 1.2-1.5N·m torque using a crowfoot wrench. Avoid overtightening - maximum
rotation angle after seal contact is 90°.
| Property | Property Value |
|---|---|
| sku | APB16-04 |
