Airtac APB Straight Tee Fitting APB16-M20
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Standard Tee Connector APB16-M20 Technical Details
- Model: APB16-M20
- Type: Straight thread tee (equal-diameter)
- Body material: Nickel-plated brass (CuZn39Pb3)
- Thread specification: M20×1.5 (ISO 228 G3/4 optional)
- Seal type: Metal-to-metal sealing with EPDM backup
- Port configuration: 1 inlet / 2 outlets (T-shaped flow path)
- Max working pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Tube compatibility: 12mm OD nylon/polyurethane tubing
- Surface treatment: Electro-less nickel plating (8-12μm)
- Weight: 82g ±2g
- Dimensions: 38mm(L) × 28mm(W) × 28mm(H)
- Torque specification: 25-30 N·m installation torque
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered hydraulic/pneumatic distribution component featuring triple-secured leak prevention with primary thread engagement, secondary O-ring compression, and tertiary metal flange contact. The 60° tapered seat design ensures bubble-tight sealing under dynamic pressure fluctuations. Compatible with ISO 8434-1 standards for universal system integration.
- Modular pneumatic manifolds in assembly lines
- Hydraulic test bench pressure distribution
- CNC machine tool coolant line splitting
- Agricultural sprayer fluid direction control
- Compressed air branching in automotive paint shops
Installation protocol:
Apply 2.5 wraps of PTFE tape clockwise on male threads.
Use backup wrench on hex flats (22mm) during tightening to prevent body distortion.
Pressure test at 1.5× system pressure after installation.
