Airtac APB Straight Tee Fitting APB4-M12
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Straight Tee Fitting APB4-M12 Technical Details
- Model: APB4-M12
- Type: Straight thread tee connector (equal-diameter)
- Body material: Nickel-plated brass (stainless steel variant available)
- Thread standard: Metric (M12×1.25 male threads)
- Port configuration: 3 female ports (1 inlet, 2 outlets)
- Operating pressure: 0.2–1.0 MPa (29–145 psi)
- Proof pressure: 1.5 MPa (217.5 psi)
- Burst pressure: 3.0 MPa (435 psi)
- Temperature range: -20℃ to 80℃ (NBR seals) / -20℃ to 150℃ (FKM seals optional)
- Surface treatment: Electrolytic polishing with anti-corrosion coating
- Weight: 38±2 grams
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H) (body only)
- Flow coefficient (Cv): 0.45
- Leakage rate: <0.1 Nml/min under 0.5 MPa
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Compliance: RoHS 2.0 compliant
Precision-engineered tee connector featuring triple-sealed O-ring grooves (NBR standard) for leak-free pneumatic connections. The 60° cone seat design ensures secure tubing retention while allowing 360° rotational alignment capability. Anodized color bands (blue/red) indicate flow direction options.
- Modular pneumatic circuit branching in automation cells
- Compressed air distribution in packaging machinery
- Vacuum system plumbing for material handling robots
- Coolant line junctions in CNC equipment
- Laboratory instrument gas supply networks
Installation protocol:
Hand-tighten until snug, then apply 1/4–1/2 additional turn with wrench.
Use PTFE tape on male threads only. Avoid overtightening – maximum torque 12 N·m.
Perform pressure test at 1.25× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | APB4-M12 |
