Airtac APCF Female Thread Straight Connector APCF10-M10
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF Series Female Thread Straight Fitting APCF10-M10 Technical Details
- Model: APCF10-M10
- Type: Female threaded straight connector (BSPP/BSPT compatible)
- Material: Lead-free brass with nickel plating (RoHS compliant)
- Thread Standard: Metric (M10×1.0 internal thread)
- Seal Type: Integrated O-ring (NBR standard, optional FKM/Viton®)
- Pressure Rating: 0.2-1.5 MPa (29-217 PSI)
- Temperature Range: -20℃ to 150℃ (continuous operation)
- Surface Finish: Electroplated nickel (3-5μm thickness)
- Proof Pressure: 3.0 MPa (435 PSI)
- Burst Pressure: ≥6.0 MPa (870 PSI)
- Flow Coefficient (Cv): 0.45
- Weight: 28g ±1g
- Dimensions:
- Total Length: 25.5mm
- Hex Size: 14mm (AF spanner size)
- Thread Engagement Length: 10mm
- Outer Diameter: 16mm (max body width)
- Compliance: ISO 8434-1/DIN 2353 (metric tube connections)
Precision-engineered metric connector featuring dual sealing mechanism (metal-to-metal seat + elastic O-ring) for leak-free performance in dynamic pressure conditions. The hexagonal body design allows 360° rotational adjustment post-installation. Compatible with air, water, and non-corrosive hydraulic fluids.
- Modular pneumatic circuit assembly in automation cells
- Coolant line connections for CNC machining centers
- Vacuum system interfaces in packaging machinery
- Instrumentation tubing in semiconductor fab equipment
- Mobile hydraulic systems requiring metric fittings
Installation guidelines:
Apply PTFE tape or liquid sealant to male threads only.
Tighten to 12-15 N·m torque using calibrated wrench.
Avoid cross-threading by hand-starting 3 full turns before final tightening.
Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APCF10-M10 |
