Airtac APCF Female Thread Straight Connector APCF10-M20
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF Series Female Thread Straight Fitting APCF10-M20 Technical Details
- Model: APCF10-M20
- Type: Female threaded straight connector (ISO 1179 metric standard)
- Material: Nickel-plated brass (base) + PPS resin (housing)
- Thread specification: M20×1.5 internal thread (both ends)
- Pressure rating: 0.05–1.5 MPa (7–217 psi)
- Burst pressure: ≥6.0 MPa (870 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal type: Integrated O-ring (NBR rubber)
- Flow coefficient (Cv): 0.45
- IP rating: IP40 (dust protected)
- Weight: 128g ±2g
- Dimensions: 62mm(L) × 32mm(W) × 32mm(H)
- Surface roughness: Ra ≤3.2μm (sealing areas)
High-pressure resistant straight connector with dual-layer corrosion protection, featuring precision-machined threads for leak-free connections in dynamic pneumatic systems. The anti-vibration PPS housing maintains structural integrity under pulsating loads. Compatible with ISO 1179-1 and DIN 3859 standards.
- Industrial robot pneumatic arm joint connections
- CNC machine tool air chuck supply lines
- Packaging machinery rotary union interfaces
- Compressed air distribution manifolds
- Hydraulic test bench instrumentation ports
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten).
Maximum recommended torque: 35 N·m. Perform pressure test at 1.1×
working pressure after installation. Replace O-ring every 5,000
operating hours or 2 years (whichever comes first).
