Airtac APCF Female Thread Straight Connector APCF12-04
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF12-04 Female Thread Straight Fitting Technical Details
- Model: APCF12-04
- Thread type: Female BSPP (parallel)
- Port size: 1/8" (G1/8) × 1/4" (G1/4)
- Material: Lead-free brass CW617N
- Surface treatment: Electroless nickel plating (5-8μm)
- Seal material: NBR (nitrile) O-ring
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (continuous) / 120℃ peak
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Weight: 18.5±0.3g
- Dimensions: 32mm (L) × 16.5mm (W) × 16.5mm (H)
- Flow coefficient (Cv): 0.15
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined transition fitting with dual female threads, designed for secure 90° directional changes in compact pneumatic systems. Features triple-sealing structure (metal-to-metal thread contact + dual O-rings) for leak-free performance in high-vibration environments. Compatible with ISO 1179-2 standards.
- Modular pneumatic manifolds in packaging machinery
- Sensor mounting brackets in automated assembly lines
- Vacuum system connections for material handling
- Cooling air distribution in laser cutting equipment
- Medical gas line adapters (non-oxygen service)
Installation guidance:
Apply 1.5-2 wraps of PTFE tape on male threads (do not over-tighten -
maximum torque 3.5N·m). For vertical installations, orient larger port
(1/4") downward to prevent particle accumulation.
