Airtac APCF Female Thread Straight Connector APCF4-M12
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF Female Threaded Straight Fitting APCF4-M12 Technical Details
- Model Series: APCF (Internal Thread Straight Connector Series)
- Thread Specification: M12×1.5 (Metric Fine Thread)
- Material: Brass with Nickel Plating (Corrosion Resistant)
- Seal Type: Elastic Sealing with NBR O-ring
- Applicable Tube OD: Ø4mm (Flexible Pneumatic Tubing)
- Max Working Pressure: 1.5 MPa (15 bar/217.5 psi)
- Pressure Range: 0.2-1.5 MPa (Operational)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Port Configuration: Dual Female Threads (M12×1.5 both ends)
- Surface Treatment: Electroplated Chromate Layer (Anti-oxidation)
- Weight: 25g ±2g (Precision Casting)
- Dimensions: 32mm(L) × 16mm(W) × 16mm(H)
- Certification: ISO 8434-1/DIN 2353 Standards
- Vibration Resistance: ≤10Hz @ 2mm amplitude
High-density forged brass connector designed for leak-free pneumatic line connections in confined spaces. Features 360° rotatable threaded ports for flexible installation alignment. The chromium-plated surface prevents galling during repeated assembly/disassembly. Compatible with air, inert gases, and hydraulic fluids (NBR seal limited).
- Modular pneumatic circuit junctions in automation equipment
- Sensor mounting interfaces on robotic arms
- Compressed air distribution in CNC machinery
- Vacuum line connections in packaging systems
- Hydraulic test bench instrumentation
Installation Protocol:
Apply 2-3 wraps of PTFE tape on male threads (Do NOT over-tighten - recommended torque 12-15Nm).
For permanent installations, use medium-strength threadlocker (LOCTITE 243 equivalent).
Perform pressure test at 1.8MPa before system commissioning.
| Property | Property Value |
|---|---|
| sku | APCF4-M12 |
