Airtac APCF Female Thread Straight Connector APCF6-M20
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APCF6-M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Available in multiple models/specifications for wide application across pneumatic systems;
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
Installation protocol:
Apply PTFE tape clockwise (2.5 wraps) on male threads only.
Torque limit: 25-30 N·m (use calibrated torque wrench).
Pressure test with 1.1× working pressure after installation.
2. Features excellent flow performance with capacity equivalent to tubing inner diameter;
3. Enables tool-free push-in/pull-out operation while maintaining secure and durable tubing connections;
4. Pre-applied thread sealant with M5 metric threads and integrated sealing washers ensure leak-proof threaded joints;
5. Nickel-plated brass body provides superior corrosion and contamination resistance for expanded application scope.
Category: Internal Thread Straight Fittings | Brand: AirTAC | Series: APCF
AirTAC APCF6-M20 Female Thread Straight Fitting Detailed Specifications
- Model: APCF6-M20
- Type: Female threaded straight connector (BSPP/BSPT compatible)
- Thread specification: M20×1.5 (ISO 228/ISO 7-1 compliant)
- Material: Brass CW617N with electroless nickel plating
- Operating pressure: 0.05–1.5 MPa (7–217 PSI)
- Burst pressure: ≥6.0 MPa
- Temperature range: -20℃ to 120℃ (continuous operation)
- Seal material: NBR (Nitrile) rubber standard (FKM/Viton® optional)
- Surface roughness: Ra ≤1.6μm (sealing surfaces)
- Weight: 82g ±2g
- Dimensions:
- Total length: 38mm
- Hex size: 30mm AF (across flats)
- Thread engagement length: 12.5mm (both ends)
- Outer diameter: 24mm (maximum body diameter)
- Compliance: RoHS 2.0, REACH SVHC
High-flow pneumatic connector with dual-end female threads, featuring precision-machined leak-proof grooves and corrosion-resistant finish. The 45° chamfered entry prevents O-ring damage during assembly. Rated for 500,000+ pressure cycles with proper installation.
Typical Applications:
- Pneumatic cylinder port connections in automated assembly lines
- Compressed air distribution manifolds (ISO 15407-1 systems)
- Vacuum system interconnections for material handling
- Hydraulic test bench instrumentation (low-pressure circuits)
- Robotic end-effector tooling air supply
Installation protocol:
Apply PTFE tape clockwise (2.5 wraps) on male threads only.
Torque limit: 25-30 N·m (use calibrated torque wrench).
Pressure test with 1.1× working pressure after installation.
Compatibility Notice:
Not recommended for use with phosphate ester fluids or chlorinated hydrocarbons.
For steam applications, specify high-temp FKM seals (special order).
| Property | Property Value |
|---|---|
| sku | APCF6-M20 |
