Airtac APD T-Side Port Tee Fitting APD10-M10
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD10-M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation guidelines:
Apply thread sealant to male threads only (PTFE tape recommended).
Avoid overtightening - use torque wrench for precise installation.
Align side port perpendicular to main flow direction for optimal performance.
Compatible with tubing OD: 8-12mm (requires matching ferrule).
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Port Tee Fitting APD10-M10 Technical Specifications
- Model: APD10-M10
- Type: T-shaped pneumatic tee connector (side entry)
- Thread standard: Metric (M)
- Port size: M10×1.0 (all three ports)
- Material: Nickel-plated brass (standard) / Stainless steel optional
- Pressure rating: 0.05-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile) rubber
- Surface treatment: Electrolytic polishing
- Weight: 22g ±0.5g
- Dimensions: 30mm (L) × 16mm (W per port) × 25mm (H)
- Fluid compatibility: Compressed air, inert gases
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Installation torque: 12-15 N·m
High-flow tee connector with 90° side entry design for compact piping layouts. Features precision-machined threads with anti-vibration grooves and corrosion-resistant plating. The internal flow channel is optimized for minimal pressure drop (ΔP ≤0.02MPa @ 0.5MPa).
Common Applications:
- Branch line creation in pneumatic automation systems
- Tooling fixture air circuit distribution
- Packaging machine air manifold extensions
- Robotic end-effector pneumatic networks
- Compressed air monitoring system junctions
Installation guidelines:
Apply thread sealant to male threads only (PTFE tape recommended).
Avoid overtightening - use torque wrench for precise installation.
Align side port perpendicular to main flow direction for optimal performance.
Compatible with tubing OD: 8-12mm (requires matching ferrule).
| Property | Property Value |
|---|---|
| sku | APD10-M10 |
