Airtac APD T-Side Port Tee Fitting APD10-M12
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Connector APD10-M12 Technical Details
- Model: APD10-M12
- Type: T-shaped triple port (1 input/2 output)
- Thread standard: Metric M12×1.25
- Material: Nickel-plated brass body
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃
- Flow coefficient (Cv): 0.45
- Surface treatment: Electroless nickel plating (5-8μm)
- Anti-vibration design: Hexagonal base with dual locking grooves
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 22mm(W) × 22mm(H)
- Port-to-port spacing: 10mm center distance
- Compatibility: Works with Φ4mm/Φ6mm/Φ8mm tubing (requires adapters)
- Certification: RoHS compliant
High-density flow distribution fitting with corrosion-resistant construction, featuring precision-machined internal channels to minimize pressure drop. The 60° angular port arrangement enables compact installations in clustered pneumatic systems. Includes built-in thread protectors to prevent cross-threading during assembly.
- Modular pneumatic manifolds in robotics
- Branch line distribution for CNC machine tool changers
- Vacuum system splitting in packaging equipment
- Sensor air supply networks in semiconductor manufacturing
- Hydraulic test bench instrumentation (low-pressure circuits)
Installation protocol:
Apply 2-3 drops of pneumatic sealant (viscosity ≤350cP) on threads before tightening to 12-15N·m torque.
Avoid overtightening - full engagement achieved at 4.5±0.5 thread rotations.
| Property | Property Value |
|---|---|
| sku | APD10-M12 |
