Airtac APD T-Side Port Tee Fitting APD10-M16
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Style Tee Fitting APD10-M16 Technical Details
- Model: APD10-M16
- Type: T-port compact pneumatic tee connector
- Thread specification: M16×1.5 (ISO 228 G1/2 equivalent)
- Material: Lead-free brass (CuZn39Pb0.5) with nickel-plated surface
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥6 MPa
- Temperature range: -20℃ to 120℃ (continuous use)
- Weight: 48±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Seal material: NBR (Nitrile) with optional FKM (Fluorocarbon) upgrade
- Flow coefficient (Cv): 3.2
- Surface roughness: Ra ≤1.6μm
- Vibration resistance: 10-2000Hz, 15G acceleration
- Corrosion resistance: 96hrs neutral salt spray test
High-flow precision-machined tee connector featuring triple O-ring sealing (dynamic + 2 static seals) for leak-free performance. The 60° conical seat design ensures secure tube retention while allowing 360° rotational adjustment post-installation. Compatible with PU, nylon, and rubber tubing (8-12mm OD).
- Pneumatic circuit branching in CNC machine tooling
- Modular air distribution in semiconductor wafer handling systems
- Coolant line splitting for high-speed spindle units
- Vacuum system manifold connections
- Robotic end-effector pneumatic networks
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten with 18-22N·m torque using 24mm crowfoot wrench.
Pressure test at 1.75× operating pressure before commissioning.
| Property | Property Value |
|---|---|
| sku | APD10-M16 |
