Airtac APD T-Side Port Tee Fitting APD10-M20
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Connector APD10-M20 Technical Details
- Model: APD10-M20
- Type: T-shaped pneumatic tee connector (side port configuration)
- Body material: Anodized aluminum alloy (AL6061-T6)
- Thread specifications: M20×1.5 (ISO 228 G1/2 compatible)
- Operating pressure: 0.05–1.2 MPa
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Port configuration: 1/2" BSPP female threads (3 ports)
- Flow coefficient (Cv): 2.8
- Weight: 185g ±3g
- Dimensions: 40mm (Length) × 34mm (Width) × 34mm (Height)
- Surface hardness: HV 120-150
- Leakage rate: ≤0.1 NL/min @ 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-flow tee connector with precision-machined flow channels, featuring triple-seal technology for leak-free operation in high-vibration environments. The 60° angular port design enables space-efficient plumbing configurations while maintaining optimal airflow characteristics. Compatible with ISO 15407-1 standard pneumatic systems.
- Pneumatic circuit branching in CNC machine tooling
- Compressed air distribution in automotive assembly lines
- Packaging machinery air network junctions
- Semiconductor fab equipment gas line splitting
- Food processing pneumatic systems (FDA-compliant seal option available)
Installation protocol:
Apply 2-3Nm torque during assembly using a crowfoot wrench.
Use LOCTITE 5452 thread sealant (not included) for high-pressure
applications (>0.8 MPa). Rotate connector body no more than 180°
post-installation for line alignment.
- Optimal for Φ10mm OD polyurethane/nylon tubing
- Accepts 3/8" JIC fittings with adapter sleeve (sold separately)
- Not recommended for metric PTFE hoses above 12mm OD
| Property | Property Value |
|---|---|
| sku | APD10-M20 |
