Airtac APD T-Side Port Tee Fitting APD12-M16
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Connector APD12-M16 Technical Details
- Model: APD12-M16
- Type: T-shaped pneumatic tee connector (side port type)
- Thread specification: M16×1.5 (ISO 6149 metric thread)
- Material: Nickel-plated brass (C3604)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Seal material: NBR (Nitrile rubber)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Port configuration: 3-way equal diameter (1 inlet, 2 outlets)
- Surface roughness: Ra≤3.2μm (internal flow path)
- Weight: 48±2 grams
- Dimensions: 34mm(L) × 28mm(W) × 28mm(H)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-machined tee connector with optimized flow path design, featuring a 60° angular port arrangement for compact installations. The nickel plating provides corrosion resistance in humid environments. Internal O-ring groove design ensures leak-free connections up to 1 million cycles.
- Branch line connections in pneumatic automation systems
- Air pressure gauge manifold setups
- Modular pneumatic circuit prototyping
- Industrial robot end-effector air supply distribution
- Packaging machine air line splitting
- CNC machine tool pneumatic control circuits
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 15N·m torque).
For vertical mounting, position side port horizontally to prevent particle accumulation.
Use compatible tube OD: 12mm (1/2") with 1.5mm wall thickness.
| Property | Property Value |
|---|---|
| sku | APD12-M16 |
