Airtac APD T-Side Port Tee Fitting APD12-M20
$5.39
Regular price
$12.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD12-M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 12–15 N·m torque using crowfoot wrench.
Perform pressure test at 1.8× working pressure after installation.
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Port Tee Connector APD12-M20 Technical Details
- Model: APD12-M20
- Type: T-shaped triple port connector (metal body)
- Thread specification: M20×1.5 (ISO 228/ISO 1179 compliant)
- Material: Nickel-plated brass (base) + PPS resin (housing)
- Pressure rating: 0.2–1.5 MPa (29–218 PSI)
- Temperature resistance: -20℃ to 120℃ (continuous use)
- Flow capacity: 850 L/min (at 0.5 MPa)
- Leakage rate: <0.1 NmL/min (under 0.5 MPa pressure)
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Port configuration: 1 input + 2 output (90° right-angle branching)
- Surface roughness: Ra ≤3.2μm (flow channels)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
High-density tee connector with military-grade sealing, engineered for high-vibration environments. Features dual-stage O-ring seals (NBR material) and anti-rotation lock nuts. Compatible with air, inert gases, and vacuum systems (not for hydraulic fluids).
Industrial Applications:
- Pneumatic tool manifolds in automotive assembly lines
- Multi-axis robot end effector air supply distribution
- CNC machine tool cooling air circuits
- Semiconductor fab equipment gas line branching
- Packaging machine vacuum generator systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 12–15 N·m torque using crowfoot wrench.
Perform pressure test at 1.8× working pressure after installation.
Port matching:
Pairs with APD-M20 series quick couplings.
Not compatible with BSPP/BSPT threads without adapters.
| Property | Property Value |
|---|---|
| sku | APD12-M20 |
