Airtac APD T-Side Port Tee Fitting APD14-02
$10.04
Regular price
$17.54
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD14-02
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation protocol:
Apply thread sealant to male threads (PTFE tape not recommended for dynamic joints).
Tightening torque: 1.2-1.5 N·m for brass, 2.0-2.5 N·m for stainless steel.
Avoid overtightening - maximum 1/4 turn past finger-tight.
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD14-02 T-Port Tee Connector Specifications
- Model: APD14-02
- Type: T-shaped three-way connector (equal diameter)
- Thread standard: Metric (M5×0.8) / Optional BSPP (R1/8)
- Material: Brass (nickel-plated) / Optional stainless steel SS304
- Operating pressure: 0.05-1.5 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Surface hardness: HV200±20 (nickel plating)
- Weight: 18.5g±0.5g
- Dimensions: 30mm(L) × 14mm(W) × 14mm(H)
- Flow coefficient (Cv): 0.15
- Leakage rate: ≤0.1 NL/min @ 0.5MPa
Precision-machined pneumatic tee connector with triple sealing grooves (two O-ring seats + thread seal). Features 360° rotatable ports for flexible piping layouts. Mirror-polished internal channels minimize pressure drop, compatible with ISO 8573-1 air quality standards.
Typical Applications:
- Branch line creation in pneumatic control panels
- Sensor mounting with auxiliary air supply
- Pneumatic tool air distribution systems
- Medical gas equipment manifolds
- Robotic end-effector pneumatic networks
Installation protocol:
Apply thread sealant to male threads (PTFE tape not recommended for dynamic joints).
Tightening torque: 1.2-1.5 N·m for brass, 2.0-2.5 N·m for stainless steel.
Avoid overtightening - maximum 1/4 turn past finger-tight.
Fluid compatibility:
Not suitable for phosphate ester fluids or chlorinated hydrocarbons.
Maximum particle size: 50μm.
Lubrication: Use ISO VG32 turbine oil if required.
| Property | Property Value |
|---|---|
| sku | APD14-02 |
