Airtac APD T-Side Port Tee Fitting APD16-M20
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Connector APD16-M20 Technical Specifications
- Model: APD16-M20
- Type: T-shaped triple port connector (side entry)
- Body material: Nickel-plated brass (C3604)
- Thread specifications: M20×1.5 (ISO 6149 metric thread)
- Port configuration: 1 inlet (bottom) + 2 outlets (perpendicular)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Seal material: NBR (Nitrile) standard / Optional FKM (Viton)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 98±2g
- Dimensions: 32mm(L) × 28mm(W) × 46mm(H)
- Flow coefficient (Cv): 0.45
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Heavy-duty T-connector featuring anti-vibration thread design with 360° rotatable outlets for flexible piping arrangements. The hexagonal base allows tool tightening (24mm wrench size), while the precision-machined internal channels minimize pressure drop. Compatible with air, water, and light hydraulic fluids when using appropriate seals.
- Pneumatic manifold blocks in automation equipment
- Hydraulic test bench plumbing systems
- CNC machine tool coolant line distribution
- Compressed air branching in packaging machinery
- Vacuum system junctions for material handling
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten).
For vertical mounting, position outlets horizontally to prevent seal deformation.
Torque limit: 35-40 N·m. Always perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APD16-M20 |
