Airtac APD T-Side Port Tee Fitting APD4-01
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Style Tee Connector APD4-01 Specifications
- Model: APD4-01
- Type: T-style 3-way connector (side port configuration)
- Body material: Brass with nickel plating (stainless steel optional)
- Port sizes: PT1/8 (G1/8) x PT1/8 x PT1/8
- Thread standard: ISO 228 (BSPP)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Proof pressure: 1.5 MPa
- Weight: 28g ±1g
- Dimensions: 25mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra ≤3.2μm
- Leakage rate: ≤3 bubbles/min (under 0.5 MPa)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP40 (standard)
Precision-engineered T-connector featuring triple-port flow distribution with low pressure drop. The 90° side port design enables compact plumbing layouts in confined spaces. Electroless nickel plating provides corrosion resistance for humid environments. Compatible with air, inert gases, and water (non-potable applications).
- Pneumatic circuit branching in automation equipment
- Vacuum system manifold connections
- Coolant line distribution in CNC machines
- Laboratory gas chromatography setups
- Industrial robot end-effector air supply
Installation guidelines:
Apply 2-3Nm torque during assembly. Use thread sealant only on male threads.
Avoid overtightening - maximum recommended rotation angle after hand-tight is 2.5 turns.
Perform pressure test at 0.8MPa before full operation.
