Airtac APD T-Side Port Tee Fitting APD4-M5
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APD4-M5
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to diverse pneumatic systems;
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
Installation protocol:
Apply 1.2–1.5Nm torque during assembly. Use thread sealant only on male ports.
Avoid angular misalignment exceeding 3°. Test at 0.6MPa for 30min post-installation.
2、Superior flow performance enabling throughput equivalent to the inner diameter of connected tubing;
3、Tool-free insertion/extraction design ensures efficient tube connection with secure and durable sealing;
4、Pre-applied thread sealant on M5 metric threads with integrated sealing washer guarantees leak-proof integrity;
5、Nickel-plated brass construction provides corrosion and contamination resistance for expanded application scope.
Category: T-Port Tee Connectors , Brand: Airtac , Series: APD
AirTAC APD T-Type Tee Joint APD4-M5 Technical Specifications
- Model: APD4-M5
- Type: T-shaped pneumatic tee connector (straight thread)
- Thread standard: Metric fine thread (M5×0.8)
- Material: Reinforced PBT + 30% glass fiber (black)
- Seal material: HNBR rubber (-20℃ to 120℃)
- Operating pressure: 0.05–1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Port configuration: Three M5 female threads (1 inlet, 2 outlets)
- Surface treatment: Anti-corrosion anodizing
- Weight: 4.8±0.3g
- Dimensions: 20mm (L) × 18mm (W) × 18mm (H)
- Flow coefficient (Cv): 0.15
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Compliance: RoHS, REACH
High-density composite tee connector engineered for precision pneumatic systems requiring compact branching solutions. Features triple O-ring seals with 360° pressure distribution and anti-vibration thread design. Compatible with air/N2 (lubricated or non-lubricated).
Typical Applications:
- Modular pneumatic circuit distribution in robotics
- Sensor air supply branching in CNC machines
- Miniature pneumatic tool manifolds
- Laboratory analytical instrument gas lines
- 3D printer pneumatic control systems
Installation protocol:
Apply 1.2–1.5Nm torque during assembly. Use thread sealant only on male ports.
Avoid angular misalignment exceeding 3°. Test at 0.6MPa for 30min post-installation.
| Property | Property Value |
|---|---|
| sku | APD4-M5 |
